Alesea | Virtual Business Assistan

NEW

Alesea is your virtual assistant for cable inventory management.

Alesea transforms the cable drum from a simple package into an intelligent asset that supports customers in improving their efficiency in operations and inventory management.

Alesea makes the information about your assets always available, and autonomously updated by the solution. You get real time inventory visibility, actionable notifications and you will know each asset’s location, status, history, usage and handling conditions.

Asset localization | See where your cables and drums are located at all times.

    Read more

    Alesea

    E3X® Technology

    NEW

    Prysmian Group’s groundbreaking E3X® Technology is the utility industry’s first heat-dissipating overhead conductor that transforms the power grid through reduced power loss, increased power carrying capacity and lower costs.

    E3X Technology features a thin, durable coating that is applied to the surface of any TransPowr® overhead conductor. This heat-dissipating coating increases emissivity and reduces absorptivity, improving energy effectiveness and efficiency by allowing for a higher ampacity rating, reduced operating temperature and lower losses for a given conductor size, or reduced conductor size for a given ampacity rating—transforming power grid sustainability, reliability, resilience and cost of ownership.

    Significant first-cost and long-term operational savings

    • Up to 20% Reduced Project Costs*
    • Up to 25% Increased Ampacity*
    • Up to 25% Lower Line Loss*
    • Up to 30% Reduced Operating Temperature*

    Read More...

    E3X® Page

    Medium Voltage Cables

    Oman Cables has state of the art technology and equipment to manufacture high quality Medium Voltage up to 33kV.

    Cables such as

    • Single Core Unarmoured
    • Single Core Aluminum Wire Armoured
    • Three Core Unarmoured
    • Three Core Steel Wire Armoured
    • Three Core Steel Tape Armoured

    Range

  • 1C x 25 mm2 to 1C x 1000 mm2
  • 3C x 25 mm2 to 3C x 400 mm2
  • Specification

    IEC 60502 part 2, BS 6622, BS 7835 or any other international specification/ Customer specification. We can also produce cables with alternative sheathing material and for special applications such as reduced flame propagation, low-smoke, zero-halogen characteristics, lead sheathed cables, anti-termite treatment and UV resistance. Special features like water sealing of conductors & screens as well as different colour of the outer the sheath can be provided on request.

    Medium Voltage Cables

    Download Catalog

    Lead Sheathed Medium Voltage Cables

    Download Catalog

    Low Voltage Cables

    A) XLPE Insulated Power Cables
    600/1000V grade, plain annealed Copper conductor. XLPE insulated, multicore cables laid up and inner sheathed with PVC, round galvanized steel wire armoured for multi cores and aluminium wire armoured for single cores and outer jacket with PVC.

    Range
    From 1C x 10 mm²to 1C x 1000 mm²
    From 2C x 1.5 mm² to 4C x 400 mm²

    Specification
    BS-5467, IEC 60502, part-1;S-6724 as per Iraq specs or any other international standards, as well as customer specification. We also manufacture the cables for special applications which require enhanced fire performances as per IEC-60332-3, Low Smoke Zero Halogen characteristics as per BS6724, lead sheathed cables, anti-termite treatment, UV resistant & Water blocking feature, tinned copper wires in the armour for higher armour conductivity etc.

    B) PVC Insulated Power Cables
    600/1000V Grade Plain annealed Copper conductor, PVC insualted, multicore cables laid up and inner-sheathed with PVC, round galvanized steel wire armoured for multicores and aluminium wire armoured for single core and outer jacket with PVC.

    Range
    From 1C x 10 mm² to 1C x 1000 mm²
    From 2C x 1.5 mm² to 4C x 400 mm²

    Specifications
    IEC-60502 Part-1, as per Iraq specs or any other international standards as well as customer specifications. We also manufacture the cables
    for special applications which require enhance fire performance as per IEC-60332-1 & IEC-60332-3, lead sheathed cables, anti-termite treatment, UV
    resistant, water blocking feature, tinned copper wires in the armour for higher armour conductivity etc.

      Low Voltage Cables

      Download Catalog

      Overhead Line Conductors

      Oman Cables has capability to produce complete range of overhead line conductors in Aluminium, Aluminium Alloy and Copper. The standard range includes sizes up to 1000mm² as per BS, IEC, DIN, ASTM, or any other international standard and customer’s specifications for all voltage applications. We can also provide conductors with XLPE or PVC covering. The standard types of conductors in our present manufacturing range are as follows:

      Cables such as

      • AAC All Aluminium Conductors
      • AAAC All Aluminium Alloy Conductor
      • ACSR Aluminium Conductor Steel Reinforced
      • HDBC Hard Drawn Bare Copper conductor
      • SDBC Soft Drawn Bare copper Conductor
      • AAC + XLPE All Aluminium Conductor with XLPE insulation
      • AAC + PVC All Aluminium conductors with PVE insulation

      Overhead Line Conductors

      Download Catalog

      Building Wires & Cables

      Oman Cables produces the full range of house wiring cables from 1.5 mm² to 1000 mm² with wide range of core colours. The conductor is plain annealed solid or stranded Copper conductors insulated with PVC or Heat Resistant PVC as per BS EN 50535-3-41. Oman Cables also manufactures twin flat wires up to 6mm² with or without Earth continuity conductor.

      The complete range of Wiring cables can be manufactured using Low Smoke Zero Halogen thermosetting insulation compounds conforming to BS EN 50535-2-31 or with compounds to suit customer’s specific requirements.

        Fire Resistant Cables

        600/1000V grade , plan annealed copper conductor, glass mica tapped, XLPE insulated, multi-core cables laid up and inner sheathed with LSF (or LSOH/LSZH), round galvanized steel wire armoured and outer jacket with LSF (or LSOH/LSZH). Specifications: BS7846 (Category F2) and BS 6387 (Category, C, W & Z). These Cables are meant for maintaining circuit integrity under fire condition for 3 hours (tested for 3 hours at 950o C temperature).

          Range

        • From 2C x 1.5mm² to 4C x 400mm² From 5C x 1.5mm² to 5C x 70 mm²
        • Fire Resistant Cables

          Download Catalog

          Oil & Gas Cables

          Oman Cables Industry (SAOG) “OCI” can provide a variety of OGP related businesses (all along the supply chain) with an extensive product portfolio including LV, MV and Control and Instrumentation Cables. Solutions can be optimized to fit our customers’ needs

          A) Lead Sheathed Cables
          Lead sheathed cables are one of the main products in our extensive list. The characteristics of this category of products is designed to ensure reliable service and safe power supply in extreme conditions, such as, fluctuating operating temperatures, presence of moisture, aggressive chemicals and hydrocarbons.

          Product Range:
          Oman Cables is able to offer full product list of LV, MV and Control cables with a lead sheath for chemical, oils and moisture protection:


          • MV (Up to 33 KV) From 1C x 25 mm² to 1C x 1000 mm²; From 3C x 25 mm² to 3C x 400 mm²

          • LV (600/1000 V) From 1C x 10 mm²to 1C x 1000 mm²; From 2C x 1.5 mm² to 4C x 400 mm²

          • Control cables (600/1000 V) from 6 to 48 cores 1.5 mm² to 4 mm²

          • Instrumentation Cables Pairs and Triads up to 48, 0.5 mm² to 4 mm²


          Specifications:
          IEC 60502-1 and IEC 60502-2 are the most common specifications. We can supply based on customer’s requests, or other international standards. We also manufacture he cables for special applications which require enhanced fire & flame performance as per IEC 60331, IEC-60332-1 & IEC-60332-3. Depending upon the requirement, these cables can be supplied with PVC Sheath Compound and LSZH (Low Smoke Zero Halogen) Sheath Compounds. PVC Sheath can be of Flame Retardant (FR) Type, FROR (Flame Retardant Oil Resistant Type) and FRLS (Flame Retardant Low Smoke Type).



          B) DRYLAM ™: Environmentally friendly lead-free cables
          OCI as a major player in the Gulf Region cable industry is complementing its product offer with an outstanding alternative solution to lead sheathed cables based on and under the license of Prysmian Group’s proprietary DRYLAMTM Sheathing System technology, for environmentally friendly chemicals and moisture barriers.



          Product Range:
          Oman Cables is able to offer full product list of LV, MV and Control and Instrumentation cables with a DRYLAM™ sheath for chemical, oils and moisture state of the art and environment friendly protection:



          • LV (600/1000 V) From 1C x 10 mm²to 1C x 1000 mm²; From 2C x 1.5 mm² to 4C x 400 mm²

          • MV (Up to 33 KV) From 1C x 25 mm² to 1C x 1000 mm²; From 3C x 25 mm² to 3C x 400 mm²

          • Control cables (600/1000 V) from 6 to 48 cores 1.5 mm² to 4 mm²

          • Instrumentation Cables Pairs and Triads up to 48, 0.5 mm² to 4 mm²


          Specifications:
          IEC 60502-1 and IEC 60502-2 are the most common specifications. We can supply based on customer’s requests, or other international standards. We also manufacture the cables for special applications which require enhanced fire & flame performance as per IEC 60331, IEC-60332-1 & IEC-60332-3. Depending upon the requirement, these cables can be supplied with PVC Sheath Compound and LSZH (Low Smoke Zero Halogen) Sheath Compounds. PVC Sheath can be of Flame Retardant (FR) Type, FROR (Flame Retardant Oil Resistant Type) and FRLS (Flame Retardant Low Smoke Type). Flame performance as per IEC 60332-3-22 (Cat A) is our standard solution for PVC sheathed DRYLAM™ cables.


            Oil & Gas Cables

            Download Catalog

            Renewables

            Oman Cables Industry (SAOG) manufactures specialty cables tailored to the demands of the Renewables industry. We offer high quality cables recognized in the sector because their reliability and long life.

            Solar PV cables PRYSUN (PV) H1Z2Z2-K acc. to IEC 62930, Low Smoke Halogen Free, are intended for use in photovoltaic systems at nominal voltage rating of 1,5/1,5 kV DC. These cables are designed for the interconnection of various elements in photovoltaic systems, including panel interconnection, between panels and string boxes or from string boxes to the inverter. They are suitable for applications in/at equipment with protective insulation (Protecting Class II) and may be installed as fixed or freely suspended /movable, indoor or outdoor installation.

              Range

            • From 1C x 4mm2 to 1C x 10mm2; SnCu conductor
            • Specification

              IEC 62930 (Electric cables for photovoltaic systems with a voltage rating of 1,5 kV DC)

              Special Cables

              NEW

              AIRBAG ™: Metal Free mechanical protection
              OCI has launched an outstanding alternative solution to metallic armouring based on and under the license of Prysmian Group’s proprietary AIRBAGTM

              Oman Cables is able to offer full product list of LV, MV and Control and Instrumentation cables with an AIRBAG™ sheath for state of the art mechanical protection

                Product Range

              • LV ( up to and including 3.3 kV)
              • MV (Up to and including 33 kV
              • Control cables (up to and including 1 kV)
              • Instrumentation Cables (Pairs, Triads and Quads)
              • Specifications

                IEC 60502-1 and IEC 60502-2, the most common specifications for LV and MV cables, do not include this alternative as an armouring layer. Therefore, we are able to offer this solution as an “additional sheath” for mechanical protection, maintaining a cable construction for unarmored cables.
                We can also supply based on customer’s requests, or other international standards. Depending upon the requirement, these cables can be supplied with PVC Sheath Compounds, LSZH (Low Smoke Zero Halogen) Sheath Compounds and PE (LLDPE, MDPE or HDPE) Sheaths

                Special Cables

                Download Catalog
